BRC-X400 – PTZ 4K IP CAMERA

Solution > PTZ Camera > BRC-X400 – PTZ 4K IP CAMERA


Features of Sony BRC-X400 PTZ Camera

‧ Excellent 4K images, even in low light environments
‧ Zoom up to 80x (in FullHD) and 30x in 4K
‧ Wide 70° viewing angle
‧ NDI|HX support (via optional license)
‧ Compatible with S700PTP, CGI and VISCA control protocols
‧ Remote viewing over the internet with a web browser
‧ RTSP and RTMP* compatibility
‧ Easier and more affordable installation thanks to PoE (Power over Ethernet) support
‧ Ideal for live production. Integrated Genlock and Tally lamp
‧ Quick and uncomplicated setup. On-scene file function for applying settings to multiple cameras

Description

  • Video Output 3G-SDI/HDMI (4K output only via HDMI)
  • Zoom Ratio 30x (4K with CIZ)/40x (HD with CIZ), (Digital 12x)
  • Image Sensor 1/2.5 Exmor R CMOS
  • Signal System (Max) 3840 x 2160 30p/1080 60p
  • Horizontal Viewing Angle (Wide) Approx. 70 degrees
  • Pan/Tilt Range P : ±170 T: +90, -20
  • Max Preset Speed [deg/s] 300°/sec (Pan), 126°/sec (Tilt)
  • Number of Preset 256 (CGI)
  • Picture Freeze Preset Yes
  • Body Colour Black and White
  • Control Interface VISCA, VISCA over IP, S700PTP, CGI
  • PoE+ Yes (IEEE802.3at compatible)
  • Audio 2ch
  • IP Streaming Yes
  • External Sync In Yes
  • AC adapter DC12V
  • Option NDI® / HX
