RM-IP500 PTZ CAMERA REMOTE CONTROLLER

  • Sequence memories of camera movements.
  • Storage and retrieval of camera presets. Up to 100 presets.
  • Tally indicator
  • Compatibility with VISCA control. Up to 7 cameras via RS-422 specification.
  • Selectable assignable elements. Allows you to add additional functions to the assignable buttons.
  • Controls up to 100 BRC or SRG cameras via IP
  • Easy configuration. Automatic assignment of IP addresses and numbers for connected cameras.
  • Supports up to 5 RM-IP500 controllers in a single network
  • Setting the Camera Color Functions

Description

  • Control Input/Output VISCA RS-422 : RJ-45 x 1
  • GPI I/O (Tally In/Contact Out) : D-Sub 15-pin (female)
  • LAN : RJ-45 x 1, 10BASE-T/100BASE-TX automatically detected
  • Control signal format 9,600 bps/38,400 bps , Data : 8 bit, Stop bit : 1 (for RS-422 communication)
  • VISCA over IP communication
  • Power connector JEITA type 4 (DC IN 12V), Separate option
  • General
  • Input voltage 12V DC (10.8 to 13.2V DC)
  • Current consumption 0.24A typ.(2.4W)
  • Operating temperature 0 °C to 40 °C (32°F to 104°F )
  • Storage temperature -20 °C to 60 °C (-4°F to 140°F )
  • Dimensions (W x H x D) 306 mm x 159.3 mm x 224.1 mm (12 1/8 inches x 6 3/8 inches x 8 7/8 inches)
  • Mass Approx. 2400g
