XD234 STANDARD I/O PLAYER

Solution > Digital Signage > XD234 STANDARD I/O PLAYER


Product Applications




  • High-resolution video & images
    • XD234’s True 4K video with Dolby Vision, HDR10 and HLG transforms the viewer’s experience with bright, vibrant colors in increased detail in highlights and shadows transports you to your next destination without leaving the travel office.
  • Stunning videowalls
    • Astound your audience with dual video decoding and advanced HTML applications with frame-accurate synchronization across many screens.

Features

  • Powerful 4K video engine capable of dual video decoding of two Full HD videos simultaneously
  • Plays H.265 and H.264 encoded 4K and Full HD video
  • Supports Dolby Vision and HDR10 & HLG
  • Advanced performance HTML5 engine
  • Standard I/O package of: Gigabit Ethernet networking, Interactive controls including GPIO, IR, analog/digital audio, and an M.2 SSD PCIe interface (GPIO connectors sold separately)
  • Optional accessory, WiFi module (sold separately)

Description

VIDEO ENGINE DECODER
Native 4K@60p Dolby Vision and HDR10 video decoding
Single 4K or 1080p60 video decoding
Dual video decoding: 1080p60

MEDIA FORMATS
Video Codecs for 4K content: H.265/H.264
Video Containers for 4K H.265/H.264 content: .ts, .mov, .mp4
Video Codecs for Full HD: H.265, H.264(MPEG-4, Part 10), MPEG-2, MPEG-1
Video Containers for Full HD: .ts, .mpg, .vob, .mov, .mp4, .m2ts
Images: BMP, JPEG, PNG
Audio: MP2, MP3, AAC, and WAV (AC3 is passed through)
HTML5 (Mainstream)

DISPLAY RESOLUTIONS
4K resolutions: 4096×2160, 3840×2160, 3840×600
Upscaling to: 3840x2160x24/25/29.97/30p
1920×1200, 1920x1080x24/25/29.97/30/50/59.94/60p,
1920x1080x50/59.94/60i, 1600x1200x60p, 1440x1050x60/75p, 1440x900x60/75p, 1360x768x60p, 1280x1024x60/75p, 1280x960x60p, 1280x800x60p/75p, 1280x768x60p,
1280x720x50/59.94/60p, 1024x768x60p, 800x600x60/75p, 720x576x50p/50i, 720x480x59.94/60p/60i, 640x480x60p

HARDWARE INTERFACES
Locking Power Connector
External micro SD Slot (SDHC and SDXC); SDHC storage up to 32GB SDXC storage up to 2TB
M.2 SSD PCIe Interface
12-pin Phoenix GPIO port with 8 bi-directional GPIOs
3.5mm IR In/Out
3.5mm Audio Out (analog -or- SPDIF digital, nonsimultaneous)
HDMI 2.0a Out
Ethernet (Gigabit)
M.2 (E) Keyed Wi-Fi/Bluetooth Connector
Wi-Fi External Antenna Connector
Status LEDs (Power, Busy, Wireless, Error)
Reset and Service Buttons
Real Time Clock

Dimensions (W x H x D) 179.9 x 21.9 x 204.2mm
Weight 20 oz
Power 12V / 3A (36 Watts)
