多媒體顯示系統

解決方案 > Digital Signage

---

應用

組件

特點

• 最強大的 4K 視頻引擎，能夠同時對兩個 4K 視頻進行雙視頻解碼
• 播放 H.265 和 H.264 編碼的 4K 和全高清視頻
• 支持杜比視界和 HDR10 & HLG
• 播放 4K 全分辨率圖形
• 提供最強大的企業級性能 HTML5 引擎
• 包括以太網供電 (PoE+)
• 標準 I/O 包：千兆以太網網絡、交互式控制，包括 GPIO、IR、模擬/數字音頻和 M.2 SSD PCIe 接口（GPIO 連接器單獨出售）
• 可選配件、WiFi 模塊（單獨出售）

規格

VIDEO ENGINE DECODER
Native 4K@60p Dolby Vision and HDR10+ video decoding
Single video decoding: 4K or 1080p60
Dual video decoding: 4K or 1080p60

MEDIA FORMATS
4K full resolution graphics
Video Codecs for 4K content: H.265/H.264
Video Containers for 4K H.265 content: .ts, .mov, .mp4, .mkv
Video Codecs for Full HD: H.265, H.264 (MPEG-4 Part 10),
MPEG-2
Video Containers for Full HD content: .ts, .mpg, .vob, .mov,
.mp4, .m2ts
Image support up to 4K BMP, JPEG, PNG
Audio: MP2, MP3, AAC, and WAV (AC3 is passed through)
HTML5 (Enterprise)

DISPLAY RESOLUTIONS*
4K resolutions: 4096×2160, 3840×2160, 3840×600
Upscaling to: 3840x2160x24/25/29.97/30p
1920×1080, 1920×1200, 1600×1200, 1440×1050, 1440×900,
1360×768, 1280×1024, 1280×960, 1280×800, 1280×768,
1280×720, 1024×768, 800×600, 720×576, 720×480, 640×480

HARDWARE INTERFACES
Locking Power Connector
External micro SD Slot (SDHC and SDXC); SDHC storage up
to 32GB SDXC storage up to 2TB
M.2 SSD PCIe Interface
12-pin Phoenix GPIO port with 8 bi-directional GPIOs
3.5mm IR In/Out
3.5mm Audio Out (analog -or- SPDIF digital, nonsimultaneous)
HDMI 2.0a Out
Ethernet (Gigabit)
Power over Ethernet (PoE+)
M.2 (E) Keyed Wi-Fi/Bluetooth Connector
Wi-Fi External Antenna Connector
Status LEDs (Power, Busy, Wireless, Error)
Reset Button
Real Time Clock

Dimensions (W x H x D) 179.9 x 21.9 x 204.2mm
Weight 20 oz
Power 12V / 3A (36 Watts)

Video
